Static fittings connect tubing to other tubing, or threaded connections. Barbed connections are a clean, time tested and cost efficient method of connection. The hoop strength of the tube holds around the barbed fitting. Air Logic's first barb is free of a parting line to create a good seal, additional barbs increase holding force for tube retention.
Unit of Measure
Specifications
Brands |
N/A Air Logic |
Color |
N/A Black |
| Typical Tube Retention Pressure1 | N/A 25 psi1.7 bar |
Connection Type |
N/A Straight Port |
Tubing Inside Diameter (ID) |
N/A 1/16 in |
Static or Swivel |
N/A Tee |
Wetted Material(s) |
N/A Acetal |
EU RoHS 2 (Directive 2011/65/EU with amendment (EU) 2015/863) |
N/A Yes |
REACH (Registration, Evaluation, Authorization and Restriction of Chemicals) Compliant |
N/A Yes |
Type |
N/A Barbed |
Additional Information |
N/A
Barbed connections are free of lubrication or thread sealant used in other styles of connection. Simply push the tube over the barb and the connection is complete. Various sizes, materials, colors are available. Custom materials or colors may be available upon request. |
- 1 Subject to tubing specification
